Replacement Parts for Andis (BGCL) Head Light Clipper (63790)

Scroll down to view parts list.

Andis (BGCL) Head Light Clipper diagram #1

26049 (Diag.1) Cord
$6.74
23222 (Diag.2) Lower Housing
$3.76
60077 (Diag.3) Upper Housing
$5.80
63790-04 (Diag.4) Drive Cap (No Longer Available)
$13.20
22267 (Diag.5) Hanger Bail
$0.42
64945 (Diag.6) Rear Motor Frame
$2.20
65013 (Diag.7) Front Motor Frame
$2.30
22514 (Diag.8) Speed Control/Light Assembly(Not Available)
$25.70
21063 (Diag.9) Insulator
$0.48
27847 (Diag.10) Carbon Brush/Shunt and Terminal
$1.80
65806 (Diag.11) Brush Spring
$0.28
65805 (Diag.12) Brush Retaining Clip
$0.42
27198 (Diag.13) Motor Frame Retainer Clip
$0.42
27352 (Diag.14) Field Assembly
$37.22
21067 (Diag.15) Rubber Bearing Cup, Small
$0.32
21068 (Diag.16) Rubber Bearing Cup, Large
$0.32
15766 (Diag.17) Screw - Blade Drive
$0.32
22086 (Diag.18) Screw - Rear Housing
$0.46
21977 (Diag.19) Armature Assemby (includes #20)
$70.42
27854 (Diag.20) Metal Cam and Bearing Assy
$20.82
S20656 (Diag.21) Blade Drive Assembly
$9.88
27864 (Diag.22) Blade Hinge Screw
$0.32
23232 (Diag.23) Screw - LED Holder
$0.46
64535 (Diag.24) Lock Keeper
$0.62
64537 (Diag.25) Blade Lock - Latch
$0.70
64606 (Diag.26) Screw - Front Housing
$0.34
S63897 (Diag.27) Hinge Assembly
$14.56
60083 (Diag.28) Oil Seal
$1.10
17091 (Diag.30) Hair Seal
$0.28
64003 (Diag.32) Blade Bracket - Socket
$2.44
64027 (Diag.33) Blade Guide
$0.77
64013 (Diag.34) Tension Spring
$1.40
64139 (Diag.35) Screw - Blade
$0.66
23131 (Diag.36) LED Holder
$3.56
