Replacement Parts for Andis (AGRC) Power Groom Green Clipper (64770)

Scroll down to view parts list.

Andis (AGRC) Power Groom Green  Clipper diagram #1

63678 (Diag.1) Housing - Lower (Metallic Green)
$9.96
65198 (Diag.2) Housing - Upper (Metallic Green)
$8.38
65199 (Diag.3) Drive Cap - Metallic Green
$4.50
64902 (Diag.4) Switch Button
$0.96
64794 (Diag.5) Switch Button Lock
$0.76
64788 (Diag.6) Retainer - Switch Button
$1.10
64527 (Diag.7) Lock Ring
$1.50
64508 (Diag.8) Motor Battery Contact - (2 Required)
$1.02
64944 (Diag.9) Motor Frame - Rear
$2.26
65013 (Diag.10) Motor Frame - Front
$2.80
21067 (Diag.11) Bearing Cup - Small
$0.32
64507 (Diag.12) Switch
$2.08
57993 (Diag.13) Screw - Battery Contact
$0.28
64503 (Diag.14) Copper Brush with Shunt
$1.74
65806 (Diag.15) Brush Spring
$0.28
65805 (Diag.16) Retaining Clip - Brush
$0.42
64514 (Diag.17) Motor Frame Clip
$0.86
64726 (Diag.18) Armature Assembly
$34.66
27251 (Diag.19) Metal Cam & Bearing Assembly
$10.72
64529 (Diag.20) Field Assembly
$29.50
15766 (Diag.21) Screw - Blade Drive
$0.32
S20656 (Diag.22) Blade Drive Assembly
$7.40
21068 (Diag.23) Bearing Cup - Large
$0.32
64027 (Diag.24) Blade Guide
$0.77
64013 (Diag.25) Tension Spring - Blade
$1.40
64139 (Diag.26) Screw - Blade
$0.66
64003 (Diag.27) Blade Bracket - Socket
$2.44
64784 (Diag.28) O-ring
$0.60
64535 (Diag.29) Lock Keeper
$1.08
64537 (Diag.30) Blade Lock - Latch
$1.40
27864 (Diag.31) Screw - Blade Hinge
$0.32
S63897 (Diag.32) Hinge Assembly
$15.28
64606 (Diag.33) Screw - Housing (Long)
$0.34
64754 (Diag.35) Foam Pad
$0.48
65537 (Diag.35) Metal Leaf Spring
$0.34
60083 (Diag.36) Oil Seal
$1.10
64526 (Diag.37) Positive Lead Wire (not shown)
$0.34
