Replacement Parts for Andis (BGR) Clipper (64550)

Scroll down to view parts list.

Andis (BGR) Clipper diagram #1

65961 (Diag.1) Lower Housing
$5.60
63846 (Diag.2) Upper Housing
$13.04
68362 (Diag.3) Drive Cap
$3.86
64902 (Diag.4) Switch Button
$0.96
64794 (Diag.5) Switch Button Lock
$0.76
64788 (Diag.6) Switch Button Retainer
$1.10
64527 (Diag.7) Lock Ring
$1.50
64508 (Diag.8) Motor Battery - Contact
$1.02
64944 (Diag.9) Rear Motor Frame
$2.26
65013 (Diag.10) Front Motor Frame
$2.80
21067 (Diag.11) Small Bearing Mounting Ring
$0.32
64507 (Diag.12) Switch
$2.08
57993 (Diag.13) Screw
$0.28
64503 (Diag.14) Brush with Shunt
$1.74
65806 (Diag.15) Brush Spring
$0.28
65805 (Diag.16) Brush Retaining Clip
$0.42
64514 (Diag.17) Motor Frame Clip
$0.86
64726 (Diag.18) Armature Assembly
$34.66
27251 (Diag.19) Cam Assembly
$10.46
64529 (Diag.20) Field Assembly
$18.00
15766 (Diag.21) Screw
$0.32
S20656 (Diag.22) Blade Drive Assembly
$9.88
21068 (Diag.23) Large Bearing Mounting Ring
$0.32
64027 (Diag.24) Blade Guide
$0.77
64013 (Diag.25) Tension Spring
$1.40
64139 (Diag.26) Blade Screw
$0.66
64003 (Diag.27) Blade Bracket
$2.44
64784 (Diag.28) O-Ring
$0.60
27864 (Diag.29) Blade Hinge Screw
$0.23
S27091 (Diag.30) Hinge Assembly
$8.30
64606 (Diag.31) Housing Screw
$0.34
65537 (Diag.32) Leaf Spring
$0.34
60083 (Diag.33) Oil Seal
$1.10
64725 (Diag.35) Battery Pack
$57.65
