Replacement Parts for Aesculap FAV5 (GT105K)
Parts Diagram
Not yet available for this model
105-01
(Diag. #1) Circuit Board / PCB
$79.62
105-02
(Diag. #2) Housing - Lower
$30.64
105-03
(Diag. #3) Housing - Upper
$15.86
105-04
(Diag. #4) Air Filter
$8.51
105-05
(Diag. #5) Gear/ Worm Wheel
$58.01
105-06
(Diag. #6) Front Rubber Ring - Bearing
$2.97
105-07
(Diag. #7) Fields / Stator
$162.54
105-08
(Diag. #8) Armature / Rotor
$195.49
105-08A
(Diag. #8) Fan / Impeller - Armature
$6.62
105-09
(Diag. #9) Drive Lever
$10.82
105-10
(Diag. #10) Clamp - Power Cord
$1.00
105-14
(Diag. #14) Rear Rubber Ring - Bearing
$2.87
105-16
(Diag. #16) Felt Seals - Lever
$1.13
105-17
(Diag. #17) Felt Disc
$0.57
105-18
(Diag. #18) Strian Relief / Cord Protector
$6.62
105-19
(Diag. #19) Hanger / Bale
$2.84
105-20
(Diag. #20) Collette / Drive Roller
$5.17
105-22
(Diag. #22) Carbon Brush - Motor (2 Required)
$11.66
105-23
(Diag. #23) Power Cord - Out of Stock ETA 2 weeks
$28.35
105-24
(Diag. #24) Screw - Circuit Board (2 Required)
$0.57
105-25
(Diag. #25) Circlip / E Clip
$1.00
105-26
(Diag. #26) Screws - Housing / Cord Clamp (6 Required)
$0.95
105-30
(Diag. #30) Washer - Gear
$0.95
105-31
(Diag. #31) Hinge / Latch and Screws
$30.64
105-32
(Diag. #32) Switch
$8.98
105-35
(Diag. #35) Rubber Protection - Switch
$7.10
105-36
(Diag. #36) Bearing - Front (Armature)
$18.90
105-37
(Diag. #37) Bearing Rear - Armature
$17.01
105-38
(Diag. #38) Connector Block - Circuit Board
$1.97
