Replacement Parts for Aesculap Favorita II (GT104)
104-01
(Diag. #1) Circuit Board / Conductor Plate
$79.63
101-02
(Diag. #2) Motor Bottom Housing
$25.47
101-03
(Diag. #3) Motor Top Housing
$22.68
101-04
(Diag. #4) Air Filter
$8.51
101-05
(Diag. #5) Worm Wheel
$71.82
104-06
(Diag. #6) Rubber Ring - Bearing (Rear)
$3.59
104-07
(Diag. #7) Field Coil
$162.54
104-08
(Diag. #8) Armature / Rotor
$264.60
104-09
(Diag. #9) Oscillator Arm / Drive Lever (Blade)
$17.01
104-10
(Diag. #10) Cord Clamp
$1.00
104-11
(Diag. #11) Blade Mount / Dove Tail
$12.50
104-12
(Diag. #12) Spring - Blade Release Lever
$1.42
104-13
(Diag. #13) Insulator Plate - Circuit Board
$1.80
104-14
(Diag. #14) Rubber Ring - Bearing (Front)
$3.59
104-16
(Diag. #16) Felt Seal - Drive Lever (2 Required)
$1.13
104-17
(Diag. #17) Felt Disk
$0.75
104-18
(Diag. #18) Strain Relief / Cord Protector
$6.62
104-19
(Diag. #19) Hanger / Bale
$2.84
104-20
(Diag. #20) Sliding Ring
$1.80
104-21
(Diag. #21) Release Lever - Blade
$27.41
104-22
(Diag. #22) Carbon Brush without spring (2 Required)
$11.10
104-23
(Diag. #23) Power Cord
$36.73
104-24
(Diag. #24) Screw - Circuit Board (2 Required)
$0.57
104-25
(Diag. #25) Circlip / E Clip
$1.00
104-26
(Diag. #26) Screw - Housing (4 Required)
$0.95
104-27
(Diag. #27) Screw - Cord Clamp (2 Required)
$0.95
104-28
(Diag. #28) Screw - Circuit Board Insulator (2 Required)
$0.57
104-30
(Diag. #30) Washer - Gear / Drive Lever (Underneath - 2 Required))
$0.95
104-31
(Diag. #31) Screw - Dovetail / Blade Slide (4 Required)
$0.95
104-32
(Diag. #32) On / Off Switch
$8.98
104-36
(Diag. #36) Bearing - Armature (Front)
$11.34
104-37
(Diag. #37) Bearing - Armature (Rear)
$28.35
104-40
(Diag. #40) Fan - Armature (Not Shown)
$11.50
