Replacement Parts for Liscop Equi-Clip (TA9000)
19 3030101
(Diag. #1) Adjusting Screw
$3.78
19 3030102
(Diag. #2) Clipping Head Housing
$71.19
19 3030103
(Diag. #3) Pressure Bolt
$1.40
19 3012014
(Diag. #4) Tension Spring
$0.89
19 3030105
(Diag. #5) Sliding Bolts Support
$9.45
19 3030106
(Diag. #6) Sling Bolts
$1.79
19 3030107
(Diag. #7) Eccentric Block
$6.72
19 3030108
(Diag. #8) Eccentric
$20.48
19 3030109
(Diag. #9) Carrier (Yoke)
$47.51
19 030523
(Diag. #12) Blade Screw
$3.05
19 3030113
(Diag. #13) Yoke Screw
$1.31
9004001065022
(Diag. #14) Screw for hand protection
$0.42
19 3030115
(Diag. #15) Hand protection
$1.10
19 3030117
(Diag. #17) Oscillating Spring, Right
$5.25
19 3030118
(Diag. #18) Oscillating Spring, Left
$5.25
19 3030119
(Diag. #19) Gear Cover Plate
$0.89
19 3030127
(Diag. #20) Spur Gear with Shaft
$35.28
9035001362122
(Diag. #23) Screw - Gear Cover Plate
$0.53
9004004065022
(Diag. #27) Screw- Head to Motor
$0.74
9043000072022
(Diag. #28) Washer- Head to Motor Screw
$0.32
19 3030104
(Diag. #30) Nut
$0.89
19 0350212
(Diag. #31) Cord and Plug
$12.44
19 3007212
(Diag. #32) Air Filter
$4.73
9003001065022
(Diag. #33) Screw- Air Filter
$0.32
19 3007214
(Diag. #34) Brush Cap
$3.47
19 3007215
(Diag. #35) Carbon Brush
$3.78
19 3006216
(Diag. #36) Brush Spring
$1.05
19 3007301
(Diag. #38) O Ring- Front Bearing
$0.82
19 0300003
(Diag. #39) Ball Bearing- Front
$11.55
19 3007312
(Diag. #40) Retaining Ring
$0.32
193031321
(Diag. #41) Armature
$240.87
193031322
(Diag. #42) Stator (Fields)
$131.78
193031323
(Diag. #43) Motor Housing
$19.58
193007313
(Diag. #44) Brush Holder
$1.40
193031325
(Diag. #45) Circuit Board Assbly.
$61.74
193006226
(Diag. #46) Cable Contact Block
$2.52
9003001810022
(Diag. #47) Screw- Cord Fastener
$0.58
193006228
(Diag. #48) Cord Fastener
$1.05
193006229
(Diag. #49) Cord Protector
$3.05
193006230
(Diag. #50) Switch Arm
$4.62
193006231
(Diag. #51) Condenser
$48.74
193006232
(Diag. #52) On/Off Switch
$13.44
193031333
(Diag. #53) Motor Safety Switch
$19.32
193006234
(Diag. #54) Securing Ring
$0.58
193006235
(Diag. #55) Ball Bearing- Rear
$13.97
19 3007305
(Diag. #56) Oring- Rear Bearing
$0.86
19 3006237
(Diag. #57) Shimwasher
$0.86
19 3007306
(Diag. #58) Spring Washer
$1.11
19 3031339
(Diag. #59) Rear Housing Cover
$5.80
9003000465022
(Diag. #60) Screw- Switch Button
$0.56
19 3031343
(Diag. #61) Switch Button
$2.14
193031344
(Diag. #62) Motor Housing- Upper
$18.42
193006502
(Diag. #63) Aluminum Flange
$18.69
9035001065022
(Diag. #64) Screw- Aluminum Flange
$0.46
99709
(Diag. #65) Screw- Motor Housing (Not Shown)
$0.63
