Replacement Parts for Liscop Power-Clip (TA11000)
19 3030101
(Diag. #1) Adjusting Screw
$3.78
19 3030102
(Diag. #2) Clipping Head Housing
$71.19
19 3030103
(Diag. #3) Pressure Bolt
$1.40
19 3012014
(Diag. #4) Tension Spring
$0.89
19 3030105
(Diag. #5) Sliding Bolts Support
$9.45
19 3030106
(Diag. #6) Sling Bolts
$1.79
19 3030107
(Diag. #7) Eccentric Block
$6.72
19 3030108
(Diag. #8) Eccentric
$20.48
19 3030109
(Diag. #9) Carrier (Yoke)
$47.51
19 0305023
(Diag. #12) Blade Screw
$2.95
19 3030113
(Diag. #13) Yoke Screw
$1.31
9004001065022
(Diag. #14) Screw for hand protection
$0.42
19 3030115
(Diag. #15) Hand protection
$1.10
19 3030117
(Diag. #17) Oscillating Spring, Right
$5.25
19 3030118
(Diag. #18) Oscillating Spring, Left
$5.25
19 3030119
(Diag. #19) Gear Cover Plate
$0.89
19 3030130
(Diag. #20) Spur Gear with Shaft 32
$26.38
903500136122
(Diag. #23) Screw-Gear Cover Plate
$0.48
9004004865022
(Diag. #27) Screw- Head to Motor
$0.82
9045000053022
(Diag. #28) Washer- Head to Motor Screw
$0.32
19 3030104
(Diag. #30) Nut
$0.89
19 0350212
(Diag. #31) Cord and Plug
$12.44
19 0351203
(Diag. #31) Gearbox V-TD
$5.83
19 0340004
(Diag. #32) Gear Wheel
$24.91
9005000053022
(Diag. #33) Safety Disc.
$0.82
19 0350201
(Diag. #34) Motor Housing, Lower Part
$11.55
19 0332102
(Diag. #35) Armature 350 watts, complete
$151.32
19 0300102
(Diag. #37) Ventilating Fan
$2.10
19 0300005
(Diag. #38) Carbon Brush w/ Spring
$3.68
19 0300003
(Diag. #39) Ball Bearing- Front
$11.55
19 0350206
(Diag. #39) Condensor
$11.27
19 0300207
(Diag. #40) UKW condensor
$4.73
19 0300133
(Diag. #41) Bearing O ring- Rear
$0.82
19 0350209
(Diag. #42) Air Filter
$4.10
19 0350310
(Diag. #43) Motor Protection Switch
$18.08
59 0020213
(Diag. #45) Cable Protection Sleeve
$2.15
19 0500033
(Diag. #46) Cord Clamp
$0.32
9035001600042
(Diag. #47) Screw- Cord Clamp
$0.74
19 0350218
(Diag. #48) On-Off Switch
$11.92
19 0350219
(Diag. #49) Wire Connector
$1.89
19 0350220
(Diag. #50) Circuit Plate w/out Components
$2.26
19 0350321
(Diag. #51) Circuit Plate Complete
$33.62
19 0300023
(Diag. #52) Carbon Brush Holders
$1.73
19 0300024
(Diag. #53) O-Ring for Bearing
$0.74
19 0300025
(Diag. #54) Ball Bearing- Rear
$13.49
19 0350226
(Diag. #55) Stator Complete- (Fields)
$111.93
19 0350229
(Diag. #56) Motor Housing, Upper Part
$10.50
9040002500042
(Diag. #57) Screw- Motor Housing
$0.74
19 0300029
(Diag. #58) Leaf Spring- Switch Button
$1.16
19 0300030
(Diag. #59) Spring for Carbon Brushes
$1.63
19 0350237
(Diag. #60) AMP Plug
$0.42
19 0350238
(Diag. #61) Round Contact Pin
$0.68
19 0350239
(Diag. #62) Contact Spring
$1.40
19 0332135
(Diag. #64) Fixing Clamp
$26.30
