Replacement Parts for Andis (DBLC) Pulse ZR Cordless (79500)
79500-01
(Diag. #1) Screw - Housing
$0.26
79500-02
(Diag. #2) Housing - Lower
Out of Stock
79500-03
(Diag. #3) Screw - Motor
$0.32
79500-04C
(Diag. #4) Brush Retainer Clip (2 Required) - Motor (Not Shown)
$0.44
79500-04B
(Diag. #4) Brush Spring (2 Required) - Motor (Not Shown)
$0.29
79500-04A
(Diag. #4) Brush with Wire (2 Required) - Motor (Not Shown)
$1.83
79500-04
(Diag. #4) Motor
$95.36
79500-05
(Diag. #5) Housing - Upper (Assembly)
Out of Stock
79500-06
(Diag. #6) Screw - Hinge
$0.34
79500-07
(Diag. #7) Hinge Assembly (Comes with blade lock/latch)
$22.05
79500-08
(Diag. #8) Lock keeper
$1.32
79500-10
(Diag. #10) Housing - Middle
$6.59
79500-11
(Diag. #11) Screw - Circuit Board
$0.26
79500-13
(Diag. #13) Housing Assembly - Upper (Grey)
$15.44
79500-14
(Diag. #14) Blade Drive Assembly
$9.11
79500-15
(Diag. #15) Screw - Blade Drive
$0.34
79500-16
(Diag. #16) Drive Cap
$6.62
79500-17
(Diag. #17) Charge Stand
$79.57
79500-18
(Diag. #18) Charging Adapter
$35.68
79500-19
(Diag. #19) Blade Lock / Latch
$1.76
79500-21
(Diag. #21) Screw - Blade (2 Required)
$0.69
7900-22
(Diag. #22) Blade Bracket / Socket
$1.85
79500-23
(Diag. #23) Tension Spring - Blade
$1.47
7900-24
(Diag. #24) Guide - Blade
$0.25
79500-25
(Diag. #25) Foam Pad- Drive Cap
$0.95
