Replacement Parts for Andis Xperience Equine and Livestock Clipper (68050)
708-140
(Diag. #1) Clipper Head - Complete (No Blades)
$264.38
708-160
(Diag. #2) Tension Nut (Black)
$3.29
706-510
(Diag. #3) Distance Screw
$5.25
707-091
(Diag. #4) Tension Sleeve
$16.13
706-520
(Diag. #5) Screw- Head Spring
$1.06
708-141
(Diag. #6) Clipper Head Housing
$104.42
706-517
(Diag. #7) Spiral Spring
$2.84
706-511
(Diag. #8) Pressure Plate
$9.11
706-507
(Diag. #9) Crank Drive Block
$7.25
706-525
(Diag. #10) Screw- Drive Yoke (2 Required)
$1.70
706-518
(Diag. #11) Laminated Springs
$14.93
708-150
(Diag. #12) Driving Carrier / Yoke
$20.16
706-521
(Diag. #13) Blade Screw
$1.47
708-146
(Diag. #14) Centering Bushing / Ring with Flange (2 Required)
$5.66
707-088
(Diag. #15) Circlip for Crankshaft - Front
$1.26
706-524
(Diag. #16) Circlip Benzing (E-Clip)
$1.70
708-145
(Diag. #17) Crankshaft
$18.79
708-142
(Diag. #18) Sleeve / Bushing - Crankshaft
$24.05
708-143
(Diag. #19) Cogwheel / Gear
$18.99
708-070
(Diag. #30) Air Filter (Black)
$10.35
708-061
(Diag. #31) Switch Button
$1.58
708-030
(Diag. #32) Housing - Motor (Upper)
$54.86
708-062
(Diag. #33) Catch Spring / Switch Lever
$8.93
708-103
(Diag. #34) Motor 120 Volt (Complete)
$313.40
708-110
(Diag. #35) Bearing Flange (Front)
$3.15
708-138
(Diag. #36) Stator / Fields
$82.11
708-120
(Diag. #37) Ball Bearing - Armature (Front)
$12.60
708-122
(Diag. #38) Circlip / Retaining Ring
$0.32
708-133
(Diag. #39) Rotor / Armature
$188.48
701-637
(Diag. #40) Spring Disc - Rear
$1.26
708-111
(Diag. #41) Bearing Flange (Rear) with Carbon Brush Springs
$13.55
708-124
(Diag. #42) Carbon Brush Spring (2 Required)
$4.20
706-523
(Diag. #43) Screw- Head to Motor (2 Required)
$1.53
708-123
(Diag. #44) Fan Wheel - Armature
$2.09
708-118
(Diag. #45) Carbon Brushes (2 Required)
$4.20
708-115
(Diag. #46) Retaining Clamp - Motor
$0.63
708-050
(Diag. #47) Housing - Motor (Lower)
$22.58
707-082
(Diag. #48) Cable Grip
$1.66
707-081
(Diag. #49) Cable Sleeve
$4.89
708-081
(Diag. #50) Circuit Board
$111.72
708-125
(Diag. #51) Contact Wire
$1.04
707-057
(Diag. #53) Power Cord
$38.85
