Replacement Parts for Oster Model One (76175-010, 76175-310)
A1-2
(Diag. #1) Housing - Upper (Black Trim w/ Black Body)
$36.23
A1-1
(Diag. #1) Housing - Upper (Black Trim w/ Black Body)
$36.23
A1-3
(Diag. #2) Housing - Lower (Black)
$29.17
153650-000-003
(Diag. #3) Badge / Nameplate (Black Chrome)
$4.81
153264
(Diag. #4) Screw - Badge / Nameplate (2 Required)
$1.04
153660-002
(Diag. #5) Motor Assembly
$88.19
163299
(Diag. #6) Carbon Brush Set
$3.74
153667
(Diag. #7) Retaining Clip - Lever
$1.04
153674-100
(Diag. #8) Drive Lever - Blade
$6.55
153676
(Diag. #9) Hanger Hook / Bale
$4.83
42575
(Diag. #10) Hinge Assy.
$7.75
41664
(Diag. #12) Screw
$1.04
153668-100
(Diag. #13) Power Cord with AC / DC Adapter
$30.72
159499
(Diag. #14) Power Cord - Extension / Pig Tail (18 Inch US Plug)
$30.70
159463
(Diag. #15) Oring - Motor (2 Required)
$7.73
153658-002
(Diag. #17) Seal - Badge / Nameplate (Front)
$1.53
153658-001
(Diag. #18) Seal - Lever / Side (2 Required)
$4.68
153654
(Diag. #19) Seal - Badge / Nameplate (Rear)
$1.56
159822
(Diag. #20) Screw - Housing (4 Required)
$1.04
163467
(Diag. #21) PCB Assy. / Speed Control / Switch (Low Speed)
$55.84
84026-606
(Diag. #22) Screw - PCB Assy. / Circuit Board / Switch
$1.04
160329
(Diag. #23) Hair Seal - Foam (2 required)
$1.04
160498
(Diag. #24) Hair Seal - Foam
$1.04
45588
(Diag. #25) Blade Guard (Not Shown)
$1.83
